BCOTI Complete Parts Kit (3D shell and BOM)

Full parts kit to build the BCOTI (Budget Clip-On Thermal Imager) from https://github.com/Jacob-OTW/BCOTI. Everything in the BOM + 3D printed parts provided in a single neat package. You will need to provide your own tools though (soldering kit, glue, wire strippers etc).

What's Included:

3D printed parts:

• Body Shell
• Camera cage (both manual and fixed lens)
• Stem
• Display Spacer
• Stem Cover
• 1 Mounting clip of your choice (available options here, select on checkout)

Everything in the BOM:

• 1× Mini2 thermal module (256×192, 9.1 mm lens – critical version)
• 1× LZE039 OLED display + AV 3-color driver board
• 2× ESP32-C3 Super Mini*
• 10× USB-C breakout board/port*
• 1× Toggle switch (3P ON-OFF-ON)
• 1× 20 kΩ potentiometer with ON/OFF switch
• 1× 5 mm dia × 25 mm FL DCX lens
• 1× 5×5×5 mm right-angle prism
• 1× 7 mm momentary push-button
• 1× 1.25 mm 5-pin JST cable set
• M2 × 4 mm screws
• M2 × 3 mm heat-set inserts
• 26 AWG silicone wire kit. 5 colors in total, 10 meters (32 feet) each:
  • Red
  • Black

  • Yellow
  • Blue
  • Green
• Heat-shrink tubing assortment
• O-ring (OD 32 mm, CS 3.1 mm)
• 3 mm elastic band

*: Technically you only need 1 ESP32-C3 Super mini board and 1 USB-C breakout board, but I'm throwing in some extras in case you mess up and need to redo it.
